High Efficiency Product Hydraulic Pile Breaker / Construction Machinery Parts 18 modules combination Kp380

Πιστοποίηση
Κίνα TYSIM PILING EQUIPMENT CO., LTD Πιστοποιήσεις
Κίνα TYSIM PILING EQUIPMENT CO., LTD Πιστοποιήσεις
Είπα τον προϊστάμενό μου, Rafael, που συμπάθησε το προϊόν σας πάρα πολύ, ελπίζω να έχω όλο και περισσότερη επιχειρησιακή συνεργασία, δεδομένου ότι σας λέω ότι ο προϊστάμενός μου είναι πολύ ικανοποιημένος με το προϊόν.

—— Κα Bethlehem

Εντυπωσιαζόμαστε από την εμπιστευτική ποιότητα και την τέλεια υπηρεσία σας. Θα αναμένουμε με ενδιαφέρον μια καλή επιχείρηση με την επιχείρησή σας.

—— Ο κ. Win Hlaing

Είμαι Online Chat Now

High Efficiency Product Hydraulic Pile Breaker / Construction Machinery Parts 18 modules combination Kp380

High Efficiency Product Hydraulic Pile Breaker / Construction Machinery Parts 18 modules combination Kp380
High Efficiency Product Hydraulic Pile Breaker / Construction Machinery Parts 18 modules combination Kp380 High Efficiency Product Hydraulic Pile Breaker / Construction Machinery Parts 18 modules combination Kp380 High Efficiency Product Hydraulic Pile Breaker / Construction Machinery Parts 18 modules combination Kp380

Μεγάλες Εικόνας :  High Efficiency Product Hydraulic Pile Breaker / Construction Machinery Parts 18 modules combination Kp380

Λεπτομέρειες:
Τόπος καταγωγής: Jiangsu, Κίνα
Μάρκα: Tysim
Πιστοποίηση: CE/ISO900A
Αριθμό μοντέλου: KP380
Πληρωμής & Αποστολής Όροι:
Ποσότητα παραγγελίας min: 1 σύνολο
Τιμή: Negotiation
Συσκευασία λεπτομέρειες: Nude συσκευασία και γενική μεταφορά θαλασσίως με roll-on-roll-off το σκάφος Ένα επίπεδο εμπορευματ
Χρόνος παράδοσης: 45 οι εργάσιμες ημέρες μετά από έλαβαν την πληρωμή σας
Όροι πληρωμής: L/C, T/T
Δυνατότητα προσφοράς: 30 σύνολα το μήνα
Λεπτομερής Περιγραφή Προϊόντος
Διάμετρος σωρών: 600~1800 χιλ. Μέγιστη. πίεση ράβδου: 600 Kn
Μέγιστη. διαδρομή κυλίνδρου: 600 Kn

High Efficiency Product Hydraulic Pile Breaker / Construction Machinery Parts 18 modules combination Kp380 0





Technical specification 13 modules combination
KP315
18 modules combination
KP380
Pile diameter 300~1050 mm 600~1800 mm
Max. rod pressure 280 kN 600 kN
Max. cylinder stroke 135 mm 150 mm
Max. crowd pressure 34.3 MPa 34.3 MPa
Max. single cylinder flow 20 L/min 30 L/min
Quantity/8h 60/8 h 48/8 h
Max. single cutting height ≤300 mm ≤300 mm
Excavator capacity 20 35
Single module weight 100 kg 230 kg
Single module size 520*444*316 mm 696*566*350 mm
Operating size Φ2098*4000 mm Φ3316*4840 mm
Overall weight 1.7 t 4.5 t

High Efficiency Product Hydraulic Pile Breaker / Construction Machinery Parts 18 modules combination Kp380 1



High Efficiency Product Hydraulic Pile Breaker / Construction Machinery Parts 18 modules combination Kp380 2



Why Choose Us?

1. We are the first factory to design & manufacture pile breaker in China with over 5 years.

2. We have the Patent for Invention of Hydrauilc Pile Breaker in China.

3. Our pile breakers have been sold to more than 20 countries, with good feedback.

4. Using best material, our pile breaker is the best quality.

FAQ

Q1: What is the Warranty of the Hydraulic Pile Breaker?

The warranty period for new machine is half a year or 1000 working hours, whichever comes first will be applied.

Please contact with us for detailed Warranty Regulation.


Q2: What's your service ?

We can offer professional technical support and good after-sale service to you.

Modification methods will be different according to different models and configurations of your owned excavators.

Before modifying, you need to provide configuration, mechanical and hydraulic joints and others.

Before modifying, you need to confirm technical specification.
